Regulators

Swagelok KBP1G0G4A5A20000

SKU: 8030

Out of Stock

Price on request

We are not an authorized distributor, representative, or affiliate of any manufacturer or brand listed on this website

Specifications

Attribute	Value
Body Material	316 Stainless Steel
Cleaning Process	Standard Cleaning and Packaging (SC-10)
Flow Coefficient	0.20 Cv
Handle	Green Knob Handle
Maximum Inlet Pressure	250 psig (17.2 bar)
Maximum Temperature, °F (°C)	176 (80)
Port Configuration	A
Ports	1/4 in. Female NPT
Pressure Control Range	0 to 250 psig (17.2 bar)
Sensing Mechanism	X750 Diaphragm
